RTI PIKO 30

33,900.00 €

Categories: , .

Product Description

Built with the latest RTI Semiconductor Laser Module technology and a green Coherent Taipan OPSL module!
The RTI PIKO 30 is made in Germany and is a compact show laser system in a rugged, dust-proof housing that is ideally suited for top professional laser show applications of any kind. It is built with the latest RTI semiconductor laser modules that are specially designed in a way to keep spot size as well as divergence equal on both x- and y-axis. This is significantly advantageous over solutions with a very good divergence on one axis, but a bad divergence on the other.

The beam specifications of the new RTI PIKO 30 are given with only ca. 5.0 mm diameter and 0.7 mrad divergence – which applies to both axis. The extremely small beam diameter allows for the use of very small mirrors, which results in reduced inertia and thus very good scanning performance.

KEY FEATURES

30 W total RGB power in a small housing of only 271 x 491 x 296 mm
super small spot of ca. 5.0 mm for reduced inertia and thus fast scanning
extremely low divergence of less than 0.7 mrad – on both axis!
Integrated network switch for linking the control signal
Maintenance free, no misalignment: new generation of laser color combination
Compact form factor, module size equal to the Coherent OPSL modules
extremely lightweight unit with only 27 kg
Different, brighter wavelengths for increased visibility
brilliant colors and great color fading
Laser modules do not come out of internal alignment
Maintenance free laser modules
Interlock / e-stop signal can be daisy-chained
High quality product, made in Germany
Great scanning performance suitable for projections as well as for beams
The RTI PIKO 30 impresses with a guaranteed RGB output power of 30’000 mW. Great visibility is achieved with the new RTI Semiconductor Laser Modules (RSL) with special wavelengths for increased visibility: 8’000 mW / 637 nm for a very bright red combined with a strong blue laser module with 16’000 mW / 455 nm. The 10’000 mW / 530 nm Coherent Taipan OPSL green provides a warmer green tone than the 520 nm diodes and has increased visibility.
These new RSL modules with their extremely low divergence and homogenous beam shape make the RTI PIKO 30 a top professional laser system. The extremely small beam diameter of only ca. 5.0 mm allows for the use of small scanner mirrors which leads to reduced inertia and higher scan speeds. This is especially important, as the RTI PIKO 30 can be used for any kind of laser show application: Super sharp beams and vivid colors for large scale concerts and festivals but also a perfectly matched beam for crisp graphics.

The RTI Semiconductor Laser Modules are maintenance free and do not come out of internal alignment.
The standard scanners can be run at a maximum of 45 kpps@8° ILDA and a maximum scan angle of 50°. CT-6210 scanners with LAS Turboscan drivers are available as option and provide even higher scan speeds with up to 60kpps at ILDA 8°.
The housing is built very durable and ideal for use on the road. It has an interlock / e-stop through port, which allows for daisy-chaining the interlock signal, which means that only one e-stop is required for several laser systems. Control signals can be looped through directly via the network switch, which is also integrated. Due to the dustproof housing, the maintenance effort is very low and the device is also suitable for tough touring applications.The new 360° brackets can be safely fixed in the needed position in just a few moments thanks to the quick-lock system.

The powerful RTI PIKO 30 is suitable for indoor and outdoor show laser applications at concerts, festivals and other huge events. Demanding graphics projections or projections over long distances are possible without any problems, due to the extremely good divergence.

———————————

– 30 W guaranteed power
– Advanced RTI Semiconductor laser modules (RSL) produce a perfect shaped beam profile for red & blue.
– Coherent Taipan OPSL green
– Maintenance free laser system
– RSL & Coherent Taipan OPSL modules with no color misalignment
– New advanced sealed optical section with no color misalignment
– Complex graphics capable – 45 kpps@8° ILDA scanners – upgradable to 60kpps
– Full-color mixing
– Extremely sharp intense beams – low divergence
– Integrated intelligent LaserAnimation Sollinger Mainboard and ShowNET Laser Mainboard
– Integrated Touch-Display for adjustment of basic functions
– Integrated network switch for linking the control signal
– 360° Bracket with quick-lock system
– Incl. waterproof flightcase and rain cover
– operating temperature: +5°C to +45°C

———————————
